attaching old aluminu windsurfing equipment to modern base ?
Goto page 1, 2, 3, 4  Next

Post new topic   Reply to topic    iWindsurf Community Forum Index -> Windsurfing Discussion
View previous topic :: View next topic
Author Message
svenc



Joined: 08 Oct 2012
Posts: 4

PostPosted: Mon Oct 08, 2012 9:11 am    Post subject: attaching old aluminu windsurfing equipment to modern base ? Reply with quote

Hi forum. New to windsurfing. Starting by attaching as small a windsurfing sail that I can find to my skateboard. I've acquired aluminum masts & wishbones ( 15+ years old ). I cannot find anybody that sells the extension that will fit within these masts ( 2" OD, 1.925" ID ) that will allow me to connect with a mast base ( have EX pin ). Anybody know of somebody that sells or what I should modify to work ?

Thanks Sven
Back to top
View user's profile Send private message
joethewindsufa



Joined: 10 Oct 2010
Posts: 1190
Location: Montréal

PostPosted: Mon Oct 08, 2012 2:21 pm    Post subject: Reply with quote

you mean like the one in this photo?
got this at a local shop called auventfou
only place in town that carries them
their new ones are NOT as good as this one !!!
you will notice my retrofit in the pic Smile

https://fcvdqg.sn2.livefilestore.com/y1pfu_q5shsBhONT_Q6ayP9EQsBqAJTFdKhvMEu6ZJEvxbryMAYCdaW37bxhNgLi8L9o9tkGzGGASMawS3p9hMEUBgTnMBQVLTC/DSC_3022small.jpg?psid=1
Back to top
View user's profile Send private message Visit poster's website
dllee



Joined: 03 Jul 2009
Posts: 5328
Location: East Bay

PostPosted: Mon Oct 08, 2012 3:34 pm    Post subject: Reply with quote

Are u sure you have windsurfing masts?
All modern bases fit, some might need the plastic cap/collar to be adjusted/removed/replaced.
What company mast, color, length, be exact.
Back to top
View user's profile Send private message
U2U2U2



Joined: 06 Jul 2001
Posts: 5467
Location: Shipsterns Bluff, Tasmania. Colorado

PostPosted: Mon Oct 08, 2012 3:57 pm    Post subject: Reply with quote

joethewindsufa wrote:
you mean like the one in this photo?
got this at a local shop called auventfou
only place in town that carries them
their new ones are NOT as good as this one !!!
you will notice my retrofit in the pic Smile

https://fcvdqg.sn2.livefilestore.com/y1pfu_q5shsBhONT_Q6ayP9EQsBqAJTFdKhvMEu6ZJEvxbryMAYCdaW37bxhNgLi8L9o9tkGzGGASMawS3p9hMEUBgTnMBQVLTC/DSC_3022small.jpg?psid=1


the part in your photo..? the grey extension with the huge bolt thru it and pulley , it that what you mean they have....cause I a need a one of those puppys
AUVENTFOU ?

_________________
K4 fins
4Boards....May the fours be with you

http://www.k4fins.com/fins.html
http://4boards.co.uk/
Back to top
View user's profile Send private message
dllee



Joined: 03 Jul 2009
Posts: 5328
Location: East Bay

PostPosted: Mon Oct 08, 2012 4:15 pm    Post subject: Reply with quote

Your mast appears to be modern STD diameter at it's base.
So most modern mast base extensions will fit, except for NP, Streamlined, Fiberspar, and a few others that don't need plastic collars that increase the diameters.
Buy a Chinnook, pop off the top cap, but now you need to use old style adjusters.
Buy a WH, gold tube, should work as is. No euro style works, as they all are big diameter, bigger than fits in your mast.
Back to top
View user's profile Send private message
svenc



Joined: 08 Oct 2012
Posts: 4

PostPosted: Mon Oct 08, 2012 4:22 pm    Post subject: Reply with quote

joethewindsufa,

I'm not sure what it should look like, but thanks for attaching a photo.

zirtaeb,

Definately a windsurfer mast. Got it from friend who used the equipment 18+ years ago. Mistral is the brand based on the wishbone.

Just spoke with Isthmus Sailboards who said that current standard extensions should fit. Thanks for answering.

Sven
Back to top
View user's profile Send private message
svenc



Joined: 08 Oct 2012
Posts: 4

PostPosted: Mon Oct 08, 2012 4:50 pm    Post subject: Reply with quote

zirtaeb,

I think you are answering me in your latest post. STD extensions for both US and EP measure 48mm inner diameter according Isthmus website so I don't understand "No euro style works" ? What is WH, gold tube ?

Sven
Back to top
View user's profile Send private message
dllee



Joined: 03 Jul 2009
Posts: 5328
Location: East Bay

PostPosted: Mon Oct 08, 2012 5:15 pm    Post subject: Reply with quote

Glad you got an answer.
Problem here is you are asking if.... does my 1992 carbuerator fit my car? Without specifying WHAT carb and WHAT car.
Your mast should be gold colored. If it's the black ones, it's early '90's and some mast extentions don't fit inside because the inner diameter is slightly smaller.
Depending on WHICH mast extension you buy, it might or might not work.
Euro extensions are bigger in diameter and do not use a shim which makes up the size difference, so they won't fit, like Streamlined won't.
Back to top
View user's profile Send private message
U2U2U2



Joined: 06 Jul 2001
Posts: 5467
Location: Shipsterns Bluff, Tasmania. Colorado

PostPosted: Mon Oct 08, 2012 5:19 pm    Post subject: Reply with quote

apologize in advance for hi jack here

this is the extension that I use on my long board which stays in Maine.
It does function remarkable well especially with the super slippery line , the base need to be used to fit the hole of this relic board.

Does something like in the previous photo seem possible to do here, where I have a pulley on the bottom and maybe some longer extension as well ?

I did re-rig the rope this season and the board will not take much larger than the 5.8 Superfreak I used, its perfect actually.

It would downhaul and rig easier if modern. So would it work if the lower end were adapted ..?

Cheers


_________________
K4 fins
4Boards....May the fours be with you

http://www.k4fins.com/fins.html
http://4boards.co.uk/
Back to top
View user's profile Send private message
dllee



Joined: 03 Jul 2009
Posts: 5328
Location: East Bay

PostPosted: Mon Oct 08, 2012 5:26 pm    Post subject: Reply with quote

What exactly are you asking?
You can use the black N tube, if you get a N mast base to fit atop the mechanical joint.
Or, you can use your normal mast base with that foot, if you add a new mast base atop your mechanical joint.
Back to top
View user's profile Send private message
